Roof Components

At Crown we have the roof components needed for proper roof tile installation, which together with our Roof Tile and Standard Trim



The selection of the roof tile model is one of the most important processes in your project, because it is a decision that is hard to change; furthermore, aside from lasting a long time it clearly sets the architectural style of a house or project.

COLOR OXIDES



Standard Colors



Burnt Terra Cotta

Mission Terra Cotta

Nueva España

Sunburst

Indian Red

Sandhill

Madera

Sand Dune

Tortuga

Bougainvillea

Navajo

Smoked Fireclay

Cimarron

San Antonio

Impressionist

Manatee

Sand Dollar

Silverado

Birchwood

Tobacco

Ashbrown

Ironwood

Sand Canyon

French Roast

Royal Plum

Sequoia

Barkwood

American Oak

New Florida





Premium Colors

Everglades

Sea Green

Polar White*

Charcoal Black

Moonlight Gray

Red Flint

Thunderstorm







COS001

COS001

COS001

COS001

COS002

COS003

COS004

COS004

COS004

COS005

COS005

COS005

COS006

COS006

COS007

COS007

COS008

COS009

COS015

COS015

COS016

COS016

COS017

COS018

COS019

COS020

COS021

COS023

COS026







COP001

COP001

COP002

COP003

COP003

COP003

COP003

*To be mixed with white cement

COLOR OXIDES



Standard Colors



Burnt Terra Cotta: COS001

Mission Terra Cotta: COS001

Nueva España: COS001

Sunburst: COS001

Indian Red: COS002

Sandhill: COS003

Madera: COS004

Sand Dune: COS004

Tortuga: COS004

Bougainvillea: COS005

Navajo: COS005

Smoked Fireclay: COS005

Cimarron: COS006

San Antonio: COS006

Impressionist: COS007

Manatee: COS007

Sand Dollar: COS008

Silverado: COS009

Birchwood: COS015

Tobacco: COS015

Ashbrown: COS016

Ironwood: COS016

Sand Canyon: COS017

French Roast: COS018

Royal Plum: COS019

Sequoia: COS020

Barkwood: COS021

American Oak: COS023



 New Florida:COS026







Premium Colors



Everglades: COP001

Sea Green: COP001

Polar White*: COP002

Charcoal Black: COP003

Moonlight Gray: COP003

Red Flint: COP003

Thunderstorm: COP003

*To be mixed with white cement

EASY FORM PLUS

Universal Flashing with extra metal grid



Easy Form Plus® is a lightweight, environment friendly universal flashing that can be used for the sealing of almost any part of the roof.  The material is flexible up to 30% due to its crepped paintable aluminum surface composite.  It comes with an extra metal grid that molds easily to the contours of the roof and walls and is particularly effective on corners. The butyl underside makes it very durable and it does not suffer from wind uplift.

1. Paintable creped aluminium composite



2. Metal grid



3. Butylon backing



4. Release paper - divided in two strips



The choice is yours!

Easy Form Plus® is a safe, lead-free product, that is easier to use and less expensive than lead and it provides superior performance.  Simply cut and form to size needed and it’s ready to be installed directly on the roof.

Min roof pitch



Resistance



Temperature resistance



Installation temperature



Butyl adhesive



UV stability



Thickness

≥10° or 2/12



Does not rot, is weather-resistant, resistant to frost, aging & changes in temperature



-68º to +176º F



+41º to +104º F



Should be applied to suitable surfaces only, which are dry & dust free



UV stable due to metallic upper surface



1.2 mm Water column. Watertight

ACRYLIC SEALER

Features and Benefits:

• Bonds with concrete to form a Water-Proof substrate

• Reduces Ultra Violet Fading

• Stops Efflorescence from occurring

• Retards Mold and Mildew from growing

• Sealed less porous tiles will provide self-cleaning properties with wind and rain

• Easy to apply direct application formula

   *Available in one gallon and five gallon containers
